This high-voltage switching module is the “electronic successor” to the conventional mechanical servo add-on switch.
Designed for high loads and voltages. Consumers, such as pumps, can be switched on and off conveniently by sender and receiver.
The module is connected to an output of the receiver and switches the voltage of the external power battery of your consumer on or off using the joystick or switch of the transmitter.
Switching functions:On / Off (buffered).
Maximum switchable voltage: 5-cell LiPo batteries, 14-cell NiMH batteries, (21.5V).
Designed for current up to 16A.
The module is powered via the receiver battery up to a maximum of 8.5V (2-cell LiPo batteries).
Specification
Dimensions (LxWxH) 16 x 13 x 4 mm
All-up weight, approx. 8 g
